COOLED · MWIR · TURNKEY ISR

Neutrino Ground ISR Series

Detector, continuous-zoom lens, and camera electronics — factory-integrated for long-range ISR.

Turnkey MWIR cameras that combine Teledyne FLIR OEM detector modules and continuous-zoom optics with AgileCore™ image-processing and control electronics from InVeo Designs. The lineup covers short, mid, and long-range ISR — from a 1.2 kg gimbal payload out to vehicle detection past 30 km.

Band: MWIR 3.4–5.1 µm
Resolution: 640×512 or 1280×1024
Vehicle detection: 17 – 34 km
Weight range: 1.2 – 14.5 kg

Neutrino Ground ISR Series thermal camera core

UNIT · NEUTRINO-GROUND-ISR

Overview

Each Ground ISR camera is a complete imaging system: a HOT MWIR detector (InSb on the ISR 1200), a fully integrated continuous-zoom lens with through-zoom focus and boresight retention, a long-life linear Stirling cooler, and industry-standard AgileCore™ electronics. Factory-integrated and optimized from a single source, they reduce development risk, cost, and time to market.

Because they carry the AgileCore™ camera electronics, they output finished video — 720p60 / 1080p30 HD-SDI plus NTSC and PAL — alongside 14-bit Camera Link and optional Gigabit Ethernet. That is the line between a Ground ISR camera and a bare Neutrino IS core, which would need separate electronics to produce those outputs. Low switching cost makes them drop-in upgrades for existing ISR systems.

Every model runs Teledyne FLIR's Prism™ AI detection, tracking, and classification models, and Prism ISP libraries for super-resolution, turbulence mitigation, and contrast enhancement.

IS module vs. ISR camera

The Neutrino IS Series is a camera module plus lens, for integrators building their own electronics. Ground ISR adds the third layer — image processing and interface electronics with standard video outputs — so it drops into a system as a finished camera.

Key Features

AgileCore™ electronics by InVeo Designs
Camera Link 30 Hz or GigE + HD-SDI
Prism™ AI + ISP compatible
Linear Stirling cooler, up to 27,000 hrs
Motorized zoom / focus, continuous autofocus
Two-year single-source warranty

Typical Applications

Border & coastal surveillanceCritical infrastructureCounter-UASPerimeter securityShort / mid / long-range ISR

SpecificationsMWIR

Detector

Type: Cooled MWIR (HOT; InSb on ISR 1200)
Spectral band: 3.4–5.1 µm standard (ISR 1200: 3.4–5.0)
Resolution: 640×512 or 1280×1024
Radiometry: Not available
FPA full frame rate: 30 Hz (cores run 60 Hz; ISR electronics output 30 Hz full frame)
NUC: Factory 2-pt + runtime 1-pt refresh; 8 op modes

Optics

Zoom: Continuous optical, per-model ranges in table
Zoom time: <2 s min-to-max (ISR 1200: 4 s)
Boresight drift: <0.15 mm through zoom
Focus: Motorized; focus-to-distance, infinity, continuous AF
Shutter: Integrated, for 1-point FFC

Electronics

Communication: RS-422 UART, up to 921,600 baud
Digital output: Camera Link (Base) 14-bit @ 30 Hz; optional GigE
Display output: 720p60 / 1080p30 HD-SDI, NTSC, PAL
Input voltage: 12.5 VDC @ 0.7 A nom. (ISR 1200: 24 VDC)

Environmental

Operating temp: -40°C to +71°C (ISR 1200: -30°C to +70°C)
Storage temp: -57°C to +80°C
Cooler MTTF: Up to 27,000 hrs (ISR 1200: 25,000 hrs)

Compliance & Export

NDAA / ITAR: NDAA compliant · ITAR free

Representative specifications — multiple resolutions, lenses, and interface configurations are available. Request the full datasheet for your application.

Why Neutrino Ground ISR

Designed for Integrators

Industry-adopted AgileCore™ imaging electronics with an integrated MWIR camera and CZ lens deliver optimum performance and compatibility.

Industry-standard camera and lens control interface by InVeo Designs
Camera Link 30 Hz or Gigabit Ethernet, plus 1080p30 / 720p60 HD-SDI, NTSC, or PAL video
Comprehensive integration documentation
Dedicated application-engineering and support team

Drives System-Level Performance

The right focal lengths, MWIR HD or SD cameras with long-life linear coolers, and fully integrated CZ optics maximize DRI.

MWIR VGA (640×512) or SXGA (1280×1024) sensors for optimal thermal sensitivity
Through-zoom focus and boresight retention for superior autofocus and focus-to-range
Compatible with Prism™ AI models and ISP libraries
Near diffraction-limited performance, image quality optimized −40 °C to 71 °C

Teledyne FLIR Quality

The performance, reliability, and support expected from Teledyne FLIR — and the industry's most versatile HD MWIR portfolio.

Long-life Linear Stirling cooler, MTTF over 27,000 hours
Industry-leading two-year warranty from a single source
Fully vertically integrated CZ lenses developed by Teledyne FLIR
NDAA compliant and ITAR-free

Range · Detect, Recognize, Identify

Reach scales with the lens.

DetectionRecognitionIdentification

Modeled ranges against a vehicle-sized target at 50% probability, using industry-standard NV-IPM software. The lineup runs from a compact 1.2 kg short-range payload to a 34 km detection system.

LC ISR 20-420

640×512 · 1.2 kg

8.1

6.3

SX8 ISR 15-300

1280×1024 · 1.5 kg

17.4

7.3

5.7

SX8 ISR 35-700

1280×1024 · 8.55 kg

31.5

19.5

SX8 ISR 50-1000

1280×1024 · 12.2 kg

23.5

SX12 ISR 1200

1280×1024 InSb · 14.5 kg

km · vehicle target · 50% — Ranges are modeled estimates for comparison, not a performance guarantee. Actual range depends on target, atmosphere, and scene.

Shared across the series

Communication: RS-422 UART COM, up to 921,600 baud
Digital output: Camera Link (Base), 14-bit NUC-corrected at full frame, 30 Hz · optional Gigabit Ethernet
Display output: 720p60 / 1080p30 HD-SDI (SMPTE), NTSC, PAL · 10-bit (14-bit optional), fully processed
FPA full frame rate: 30 Hz
NUC: Factory: two-point (gain/offset), one-point update, defective/noisy-pixel detection, 8 op modes (2 NUC tables each) · run-time one-point refresh
Zoom & focus control: Motorized · zoom to specified angle, preset FOV · focus to distance / infinity · commanded & continuous autofocus
Shutter: Integrated shutter for 1-point flat-field correction (FFC)
Warranty: Two-year, single-source (Teledyne FLIR)

Every model, side by side

Complete configuration data from the Teledyne FLIR Neutrino ISR Series datasheet. Rows shared across the whole series are listed above; per-model values follow.

	LC ISR 20-420	SX8 ISR 15-300	SX8 ISR 35-700	SX8 ISR 50-1000	SX12 ISR 1200
Imaging & Detector
Sensor material	HOT MWIR	HOT MWIR	HOT MWIR	HOT MWIR	InSb
Spectral band	3.4–5.1 µm	3.4–5.1 µm	3.4–5.1 µm	3.4–5.1 µm	3.4–5.0 µm
Resolution	640 × 512	1280 × 1024	1280 × 1024	1280 × 1024	1280 × 1024
Pixel pitch	15 µm	8 µm	8 µm	8 µm	12 µm
Cooler	FLIR FL-100 Stirling	FLIR FL-100 Stirling	FLIR FL-100 Stirling	FLIR FL-100 Stirling	Cobham Carleton LC1062
Cooler MTTF	27,000 hrs	27,000 hrs	27,000 hrs	27,000 hrs	25,000 hrs
Boresight drift, thru zoom	<0.15 mm	<0.15 mm	<0.15 mm	<0.10 mm	0.10 mm + align tol.
Min → max zoom time	<2 s	<2 s	<2 s	<2 s	4 s
Lens
Lens type	21× continuous zoom	20× continuous zoom	20× continuous zoom	20× continuous zoom	10× continuous zoom
Focal length	20–420 mm	15–300 mm	35–700 mm	50–1000 mm	120–1200 mm
HFOV (wide → tele)	27.5° – 1.3°	39.1° – 2.0°	16.65° – 0.84°	11.69° – 0.59°	7.2° – 0.72°
F-number	f/5.5	f/4.0	f/4.0	f/4.0	f/5.0
Physical
Length	20.3 cm	20.3 cm	47.5 cm	48.18 cm	63.75 cm
Lens diameter	8.9 cm	9.65 cm	21.72 cm	30.48 cm	29 cm
Weight	1.2 kg	1.5 kg	8.55 kg	12.2 kg	14.51 kg
Electrical & Environmental
Input voltage	12.5 VDC	12.5 VDC	12.5 VDC	12.5 VDC	24 VDC
Operating temp	−40 to +71 °C	−40 to +71 °C	−40 to +71 °C	−40 to +71 °C	−30 to +70 °C
Storage temp	−57 to +80 °C	−57 to +80 °C	−57 to +80 °C	−57 to +80 °C	not specified
Range — DRI, vehicle target, 50% (km)
Detection	20	17.4	31.5	34	31
Recognition	8.1	7.3	19.5	23.5	20
Identification	6.3	5.7	16	20	16

The SX12 ISR 1200 is the outlier in the family (highlighted column): InSb detector rather than HOT MWIR, a Cobham Carleton cooler, 24 VDC input, a −30 to +70 °C operating range, a 4-second zoom, and a 3.4–5.0 µm band. Everything shared across the series is listed in the panel above the table.
